Adding RDF Lists and Sequences To Sparql

9643210674

This particular article is a discussion about a recommendation to a given standard, that of SPARQL 1.1. None of this has been implemented yet, and as such represents more or less the muiings of a writer, rather than established functionality. Read at your peril!

Lately, I’ve been spending some time on the Github archives of the SPARQL 1.2 Community site, a group of people who are looking at the next generation of the SPARQL language. One challenge that has come up frequently has been the lack of good mechanisms in SPARQL for handling ordered lists, something that has proven to be a limiting factor in a lot of ways, especially given that most other languages have had the ability of handling lists and dictionaries for decades. As I was going through the archives, an answer occurred to me that comes down to the fact that RDF and SPARQL, while very closely related, are not in fact the same things.

RDF Lists vs SPARQL Sequences

RDF has had the notion of both a collection and a list type practically from the beginning. The RDFList structure is a fairly complex one, and, in essence, represents the underlying notion of a linked list. For example, suppose that you had a list of chapters in a book. Those chapters occur in a very definite order. For instance, my latest novel has the following chapters (with more removed for brevity) as given in Turtle:

insert data {

  book:_StormCrow a class:_Book;

        book:hasChapters (

            chapter:_Preface

            chapter:_TadpolesInStillWater

            chapter:_HoldingMrButtons

            chapter:_FeverDreamsAndNightMists

            chapter:_MirrorImages

            chapter:_DancesWithBroomsticks

            chapter:_CoffeeGods

            chapter:_Blessing

            chapter:_BornToBeWild

          )

}

Internally, Turtle uses the () braces to indicate a sequence, providing a kind of syntactical sugar over what is a considerably uglier structure.

book:_StormCrow a class:_Book;

    book:hasChapters _:listPointer.

    _:listPointer rdf:first chapter:_Preface

.

    _:listPointer rdf:rest _:b1.

    _:b1 rdf:first chapter:_TadpolesInStillWater.

    _:b1 rdf:rest _:b2.

    _:b2 rdf:first chapter:_HoldingMrButtons.

    _:b2 rdf:rest _:b3.

    _:b3 rdf:first chapter:_FeverDreamsAndNightMists.

    _:b3 rdf:rest _:b4.

    _:b4 rdf:first chapter:_MirrorImages;

    _:b4 rdf:rest rdf:nil.

)}

This is a pretty basic structure using blank nodes in a chain that can be walked up one step at a time until you finally hit the predefined rdf:nil value. Each of the blank nodes can thought of as pointers to the next item in the list and to the current value of the current item in the list. The _:listPointer blank node here can then be thought of as the pointer to the whole list.

Turtle hides this unfortunate syntax, but it’s still there at the foundation of RDF, and it has been causing problems almost from the moment that the syntax was introduced in 2004. When SPARQL 1.0, came along in 2007, it borrowed the Turtle syntax for an ordered list, but couldn’t really do all that much about the structure itself. Worse, one of the unstated assumptions in SPARQL about the order in which a SPARQL query returned results, so that traversing lists in SPARQL could not guarantee that the ordered list would in fact remain ordered.

In 2013, with the advent of SPARQL 1.1, there might have been an opportunity to fix it. Sadly, it didn’t happen, and even as list manipulation became the order of the day in most modern computer languages, SPARQL remained mysteriously broken, though most implementations did in fact honor the implicit ordering of an ordered list.

One thing that’s worth noting here, and what may actually be the key to the impass, is to recognize that a list in RDF can be thought of as a datatype, but so can a list in Sparql. The distinction here is that the RDF type is actually based in the notion of triples as pointers because it is a static description of the structure, but the requirement for SPARQL is actually subtly different – the need for an interim data structure that can help facilitate queries.

Put another way, it may be worth talking about a SPARQL sequence as being different from an RDF List. What I’m proposing here is the concept that a Sequence in SPARQL should be considered closer to being an intermediate structure that may, but doesn’t necessarily have to, be represented in RDF.

For instance, consider what may be seen as a trivial function called split(), which takes a string as an argument and splits the string based upon a character sequence into multiple other strings. The result of this operation would be a Sequence, with components accessed by giving the position of the sequence.

select ?seq ?seq4 where {

    bind(“This is a test.” as ?str)

    bind(split(?str,’ ‘) as ?seq)

    bind((at(?seq,4) as ?seq4)

}

The value of ?result in this particular case would be “test”, Note that ?seq in this particular case holds a sequence of items. Depending upon the implementation the variable named ?seq would actually contain an array or list if the output was JSON.

A sequence is a set of multiple items. These items do not have to be of the same type, and can even be other sequences, dictionaries, or triples as well as literal values. They will usually be used in bind statements, but the behavior of such sequences in matching statements would depend upon the items in the sequence and the position. For instance, a sequence of iri’s in the subject position would of a matching statement would propagate into a list of matching subjects:

bind(sequence(person:_John,person:_Paul,person:_George,person:_Ringo) as ?beatles)

?beatles :memberOf band:_Beatles.

would expand out into the four matches:

person:_John :memberOf band:_Beatles.

person:_Paul :memberOf band:_Beatles.

person:_George :memberOf band:_Beatles.

person:_Ringo :memberOf band:_Beatles.

Similarly, in the object position, you’d have the corresponding associations:

band:_Beatles :hasMember ?beatles.

band:_Beatles :hasMember (person:_John person:_Paul person:_George person:_Ringo).

Similarly, in the object position, you’d have the corresponding associations:

band:_Beatles :hasMember ?beatles. band:_Beatles :hasMember (person:_John person:_Paul person:_George person:_Ringo).

which maps to the rdf list equivalent.

band:_Beatles :hasMember _:listPointer.

_:listPointer rdf:first person:_John.

_:listPointer rdf:rest _:b1.

_:b1 rdf:first person:_John.

_:b1 rdf:rest person:_Paul.

….

By differentiating the rdfList (an RDF structure) from the sequence (a SPARQL datatype) the debate of datatype vs rdf rendition can finally be put to bed.

Higher Order Functions for Sequences

One benefit of going this route is that it becomes possible to start working with higher order functions, something that SPARQL desperately needs. For instance, consider the following sequence functions.

At

at(?sequence,?index) as ?item

This retrieves the indexed item from the sequence.

Example:

bind(sequence(person:_John,person:_Paul,person:_George,person:_Ringo) as ?beatles) band:_Beatles :hasFirstMember at(?beatles,1). # This creates a triple with `person:_John` as the object.

Map

map(?sequence,expr(?this,?index)) as sequence

This iterates over an input sequence and then uses an expression to create a new sequence based upon each item in turn. The ?this property holds the current iterated value, while the ?index property gives the location of the item in the sequence.

Example:

bind(map(sequence(4,3,2,1),?this * (?index + 1)) as ?newSeq)
# This puts the sequence (8, 9, 8, 5) into the variable ?newSeq

Filters

filters(?sequence,conditional(?this,?index)) as sequence

This iterates over the sequence and returns a subsequence of those items for which the conditional expression resolves to true. This returns a sequence that will be smaller than or equal to the size of the input sequence.

Example:

bind(filters(sequence(4,3,2,1),floor(?this/2) * 2 = ?this) as ?newSeq)
# This puts the sequence (4,2) (the even numbers) into the variable ?newSeq

Reduce

reduce(?sequence, expr(?current,?acc,?index),?startValue) as item

This performs a reduce operation on a sequence doing things like adding a sequence of numbers together or computing statistical operations.

Example:

bind(reduce(sequence(4,3,2,1),?acc * ?current,1) as ?factorial)
# This generates the factorial value 4! (= 24) and points into ?factorial

Sequence

sequence(?item1 ?item2 …) as sequence

This creates a sequence of items from a list of items.

Example:

bind(sequence(person:_John,person:_Paul,person:_George,person:_Ringo) as ?beatles)
# This creates a sequence of Beatles. bind(map(sequence(4,3,2,1),floor(?this/2) * 2 = ?this) as ?newSeq) # This puts the sequence (4,2) (the even numbers) into the variable ?newSeq

ToSequence

toSequence(?) as sequence

This takes an rdf list pointer and converts it into a sequence of items, Note that this is a lossy operation – the blank nodes used as item pointers are lost in the conversion.

Example:

bind(tosequence(_:pointerListToBeattles) as ?beatles)
# This creates a sequence of Beatles from the RDF List.

FromSequence

fromSequence(?sequence, ?template) as triples*

The behavior of this is somewhat more complex, as it generates the triples necessary to support an RDF list. The exact behavior needs to be determined.

Example:

construct {

      band:_Beatles :hasMembers fromSequence(?beatles)

      }

where {

      bind(sequence(person:_John,person:_Paul,person:_George,person:_Ringo) as ?beatles)

      }

# This creates an RDF List from a sequence.

Split

split(?str, ?regex) as Sequence

This takes a string and splits it into ordered items in a sequence, based upon a regular expression joining characters together.

Example:

bind (split("path/to/file.json","\/")
# This converts the expression into the sequence ("path","to","file.json").

Join

join(?sequence, ?separator) as String

This constructs a string from a sequence, using the ?separator characters to join the items together. Note that this is just a specialized form of the reduce() function.

Example:

bind (join(sequence("path","to","file.json","/")
# This creates the string "path/to/file.json"

Other functions, such as subsequence, can be derived in much the same manner from the existing sequence operators such as map(), filters(), and reduce().

Lists and Arrow Functions

Beyond lists there are other features that can be introduced in the next iteration of SPARQL, beyond just simply the RDF-Star features currently being discussed. These include, most notably, the use of Dictionary objects (which have a corresponding RDF equivalent in Containers), which have both obvious application and relatively minimal performance impact. An important aspect of both Sequences and Dictionaries is that they are immutable – they are side-effect free.

Sequences would also enable other potential additions, including two that have transformed Javascript: arrow functions and template literals. An arrow function (or Monoid) is the generalization of a function. It takes a sequence of parameters and uses these parameters to define a function that can in turn return a sequence of values. The function itself is side-effect-free. It should be noted that in the map() function above, it was necessary to predefine the variables ?item and ?index, because that cannot currently be done in Sparql. However, the operator => could be used to make such functors within bind() statements:

bind(params("strA","strB") => `concat(?strB,' ',?strA)` as ?prepend)
#creates a functor bind(?prepend(("World","Hello")) as ?message)

which would generate the message “World Hello”. The params function() turns a sequence of variable names and associates them with the expressions as a function

Template Literals are used in several languages (under various names), and work by replacing parameters within a specialized string (in Javascript denoted by the backtick character ( ` ) with the values of those parameters. For instance,

bind (params(“subject”,”relationship”,”object”) => `”${?subject} ${?relationship} ${?object}.”` as ?assertion)

?person1 ?relation ?person2.

?person1 rdfs:label ?person1Name.

?relation rdfs:label ?relationText.

?person2 rdfs:label ?person2Name

bind (?assertion(?person1Name,?relationText,?person2Name) as ?result)

If the labels of person1 and person2 are “Jane” and “Mary” respectively and the relationship is “is married to” then the assertion() arrow function creates the string “Jane is married to Mary.”.

What’s so significant about this is that this approach makes it possible to create declarative SPARQL functions without having to express these functions as RDF, which is both awkward and inconvenient. What’s more, by using sequences and declarative arrow functions, it makes it far easier to compose functions together in a pipeline, permitting faster processing and pre-optimization.

Conclusion

It should be stressed that all of these are contingent upon having a sequence object in place, and that none of what is given above currently exists in any implementation. Efficient and readily codable sequence processing is essential for so many tasks, including analytics and machine learning, and it is time for SPARQL to be upgraded, or risk see it becoming increasingly irrelevant.
